Products Description
Our freeze dry fruit machine can handle a wide variety of products across the food and snack industries. It is applicable for drying tea leaves such as oolong, green tea, jasmine tea, and flower tea; fruits and vegetables including strawberries, blueberries, mangoes, apples, bananas, carrots, bell peppers, loofah (luffa), mushrooms, and pumpkin; seafood and meat items such as shrimp, abalone, fish fillets, beef, chicken, and other poultry; as well as instant food powders and snacks including matcha powder, ginger powder, purple sweet potato powder, fruit crisps, whole meal foods, granulated juices, and plant-based dairy substitutes.
Technical Parameters
| Item | Specification |
|---|---|
| Power | 18KW |
| Dimension (LWH) | 3.8 × 1.2 × 1.9 m |
| Evaporation Capacity (kg/h) | 50 |
| Heating Method | Electric Heating |
| Material | SUS304 |
| Product Type | DG-05, DG-10, DG-20, DG-30 |
| MOQ | 1 Set |
| Usage | Product Freeze-Drying |
| Freeze-Dried Area | 5 sqm |
| Freezer Temperature | -50℃ ~ -80℃ |
| Working Vacuum Degree | 10 Pa ~ 130 Pa |
| Heating Method | Electric Heating |
| Box Design Pressure | -0.1 MPa |
| Loading Capacity | 50–80 kg |
| Number of Trays | 16 trays |
Our Golden Shell's freeze dry fruit machine is designed for efficient and reliable performance in food processing. With a 5㎡ drying area and dimensions of 3.8 × 1.2 × 1.9 m, it offers large capacity in a compact design. The 18 kW power system ensures stable operation, while its 12 trays (440 × 550 × 35 mm) provide even drying and consistent quality. It can handle about 75 kg of meat or 50 kg of agricultural materials, making it suitable for a wide range of applications.
Durable Stainless Steel Construction
The drying chamber and trays are made of food-grade 304 stainless steel, which is hygienic, corrosion-resistant, and long-lasting.
Large Drying Capacity
With a drying area of 5㎡ m² and a loading capacity of 50 kg, the machine is equipped with 16 trays (600×800 mm), offering flexible options for either trays or mesh trays.
Stable Temperature Control
The shelves (13 layers) use low-temperature silicone oil circulation, with a precise temperature range of -55°C to +120°C, ensuring uniform and consistent drying.
Energy-Saving Design
Operating on single or three-phase power with an 18kW rated load, the machine is designed for stable performance under a working environment of ≤40°C.
