Pillow Packing Machine
The Pillow Packing Machine manufacture!
Luohe goldenshell mechanical Equipment Co.,Ltd is Our company specializes in a variety of food machinery, especially for vegetable and fruit processing machines.
Why choose us
Our Certificate
ISO certification, CE certification
Production Equipment
There are laser welding machines, CNC cutting machines and lathe to ensure our food machines can be produced smoothly.
Production Market
Our machines have been exported to many countries, including United States, Canada, Germany, France, United Kingdom, Greece, Netherlands, Italy, Brazil, Mexico, Argentina, Saudi Arabia, United Arab Emirates, etc.
Product Application
Our products cover fruit processing machines, baking machines, meat products making machine and snacks making machines, and they are widely used in food factory, restaurant and food shop.
|
Product Model |
DZB-250X |
DZB-350X |
DZB-450X |
DZB-600X |
|
Packing speed |
40-230bags/min |
40-230bags/min |
40-150bags/min |
40-150bags/min |
|
Bag length |
65-190MM/120-280MM |
65-190MM/120-280MM |
120-280MM/150-450MM |
150-450MM |
|
Bag width |
30-110MM |
50- 160MM |
60-210MM |
80-280MM |
|
Film width |
Max.250MM |
Max.350MM |
Max.450MM |
Max.600MM |
|
Film diameter |
Max.320MM |
Max.320MM |
Max.320MM |
Max.320MM |
|
Product height |
Max.40MM |
Max.45MM |
Max.80MM |
Max.100MM |
|
Voltage |
220V 50/60Hz |
220V 50/60Hz |
220V 50/60Hz |
220V 50/60Hz |
|
Power |
2.4KW |
2.4KW |
2.8KW |
2.8KW |
Conveyor system: The machine has a conveyor system that carries the pillows to the packing area.
Automated feeding system: The machine has an automated feeding system that can feed the pillows into the machine one after the other, reducing the need for manual labor.
Pillow compressing system: The machine has a pillow compressing system that can compress the pillows to a desired thickness and shape before packing.
Plastic film roll holder: The machine has a plastic film roll holder that holds a roll of plastic film that is used to wrap the pillows.
Sealing system: The machine has a sealing system that can seal the plastic film around the pillow to create a tight, secure package.
Cutting system: The machine has a cutting system that can cut the plastic film to a desired length to create a customized package for each pillow.
Speed control: The machine has a speed control system that allows the operator to adjust the speed of the conveyor system and the packing process.
Automatic stop system: The machine has an automatic stop system that shuts down the machine if there is a problem or malfunction to ensure safety.
Application of Pillow Packing Machine
Candy, chocolate, biscuit, and bread. At present, most candy manufacturers are using pillow packaging. And candy packaging form is mainly kink packaging, pillow packaging, and folding packaging.
Disposable toothpaste, toothbrush, chopsticks, etc. The basic structure of this kind of product are similar to candy products, the difference is packaging material. Some of the food packagings with PE film, some of the composite film, while daily necessities, the packaging material requirements are not so important.
Industrial supplies, such as semi-finished toys, and even some hardware products are also used pillow packaging machine. In fact, a food pillow packaging machine is ideal for packing lots of products, including various regular and irregular items. in the packaging industry, pillow packaging machine is known as one of the most widely used packaging equipment in the packaging industry.
Medical supplies like a face mask, medical gowns, etc. The unique design and fantastic structure make these products not change shapes during the packaging process.
According to the packaged products, the size of the packaging film was set up beforehand. As the main packaging material, plastic film is used, sometimes using paper and aluminum foil as the substrate.
The membrane is sent from the feeding roller and a barrel shaped bag is formed in the bag making device.the two ends of the membrane are palm-closed, and heat and pressure are applied to the two ends of the membrane at the central sealing part, and thermal adhesion (thermal sealing) is carried out. By means of a supply and transfer device arranged in the front section (supply section) of the bag maker, the packages are continuously inserted into the tubular membrane at certain intervals. The packed goods in the cylindrical film move forward at a certain interval by pressing the conveyor belt up and down. The terminal seal (also known as top seal) device heats up the middle film between the packed goods and the packed goods. At the same time, the cutting machine cuts the packed goods and ends the packing process. Pillow type packaging machine has carried out a series of operations.
Components you should know about pillow packing machine
Control panel
The control panel is composed of a PLC touch screen, mid and end sealing temperature control, the buttons of start, stop, inching, print mark, emergency stop, and power. The PLC touch screen can be set up using language, packaging speed, bag length, etc. The preset temperature display is green, and the actual temperature is red, easy to see and adjust. The inching button is convenient to test the machine.
Feeding platform
The feeding platform is adjustable in the scope of its width, but the bag’s former size can not be adjusted. So packaging different width material needs to change bag former. There are two types of conveyor systems optional about the feeding platform. One is a feeding belt with lock catches controlled by ordinary motor control. The other one is a servo conveyor belt controlled by a servo motor. The latter can detect objects intelligently, saving film, more advanced than the former, and the price higher.
Film roll device
Film roll device is used for packaging film running smoothly. Two kinds of film rolls positions are available, above the platform or under. The upper one is suitable for those objects not easy to lose their shapes. If the products you want to package is easy to fold, you had better choose the film roll device under the platform.
Mid sealing device
If it’s an upper-film roll device, the mid sealing device is under the platform. While the mid sealing device is above on the platform for down-film roll device. The mid sealing device includes pulling film wheels, heat copper block, hand shanks for pulling wheels, etc. The pulling film wheels draw packaging film forward, then heat copper block seals two sides of the film to shape a packaging bag. The hand shanks are used to adjust the tightness of pulling wheels.
End sealing and cutting device
The end sealing also adopts heat sealing, which is integrated with the cutting device. There are spiral cutters and a horizontal cutter available. The spiral cutters include single cutter, double cutter, three cutters optional. A single cutter is suitable for long packaging length, and a three cutters device is better for short packaging length. The pillow packing machine with horizontal cutter is called reciprocating pillow type packing machine. The horizontal cutter usually matches with the sponge to exhaust some air when cutting.
FAQ
As one of the leading pillow packing machine manufacturers and suppliers in China, we warmly welcome you to buy durable pillow packing machine for sale here from our factory. All food processing machines are with high quality and competitive price.
